Phosphorus deficiency in Barley

Symptômes
Plants are stunted and show purple tints on their dark green leaves, veins and stems. The older leaves, affected first, often senesce prematurely.

Raisons
Phosphorus deficiency Spring cereals may show reddening/purpling of older leaves in cold weather. Root and stem damage or poor soil consolidation can cause similar symptoms, too.

Symptômes
Plants are stunted and show purple tints on their stems.

Raisons
Phosphorus deficiency on young plants Spring cereals may show reddening/purpling of older leaves in cold weather. Root and stem damage or poor soil consolidation can cause similar symptoms, too.

Symptômes
Plants with P deficiency are smaller than normal and show purple tints on their dark green leaves, especially on the middle of the leaf blade. K deficient leaves are even more stunted and their tips are scorched.

Raisons
P and K deficiency vs. optimum supply Spring cereals may show reddening/purpling of older leaves in cold weather. Root and stem damage or poor soil consolidation can cause similar symptoms, too.

Symptômes
Plants are stunted and show purple tints, especially on the middle of older leaves. Leaf veins and stems are concerned, too. Leaf size is dimished.

Raisons
Phosphorus deficiency Spring cereals may show reddening/purpling of older leaves in cold weather. Root and stem damage or poor soil consolidation can cause similar symptoms, too.

Symptômes
Ear size is severely stunted.

Raisons
Phosphorus deficiency (right)

Symptômes
Growth of deficient plants is severely stunted. Leaf color is a slightly paler than normal.

Raisons
Phosphorus deficiency in different levels (left) compared to healthy plant
